Application
Tire tyre clamps are suitable for all kinds of tyre handling,loading,unloading and stacking operation,widely used in to tyre industry.
Features
1.Proven durable T-beam arm aluminium frame construction
2.Superior arm-slide bearing for extended service life
3.Regenerative hydraulic valving for optimal arm speed
4.Excellent lift truck driver visibility
5.Rubber pads on clamp arms can be replaced conveniently, it is economic and practical.
6.360 degree rotation
Capacity | Roll Range | Model | Mounting Class | Mountig Angle | Long arm length | Short arm length | long arm thickness | Contact pad size | weight | effective thickness | horizontalcenter of gravity |
1200 | 410-1300 | PTR15F-013A | II | 0° | 790 | 580 | 60 | 230x1500 | 400 | 135 | 216 |
2000 | 630-1300 | PTR20F-002A | II | 0° | 825 | 570 | 45 | 300x1500 | 717 | 197 | 282 |
2000 | 630-1300 | PTR20F-002B | III | 0° | 825 | 570 | 45 | 300x1500 | 717 | 237 | 320 |
2000 | 530-1500 | PTR20F-004A | II | 0° | 955 | 775 | 95 | 300x1500 | 794 | 197 | 280 |
2000 | 530-1500 | PTR20F-004B | III | 0° | 955 | 775 | 95 | 300x1500 | 808 | 237 | 304 |
2000 | 630-1600 | PTR20F-005A/B | II/III | 0° | 955 | 775 | 95 | 300x1500 | 805 | 183/216 | 301 |
1700 | 680-1830 | PTR20F-007B | III | 0° | 1130 | 930 | 115 | 300x1500 | 880 | 239 | 445 |
1700 | 380-1830 | PTR20F-008B | III | 0° | 1130 | 930 | 115 | 300x1500 | 886 | 239 | 445 |
