Chinese wenyang machinery log loader WY968J 8ton with log grapple

I'm Online Chat Now

Chinese wenyang machinery log loader WY968J 8ton with log grapple

China Chinese wenyang machinery   log loader WY968J 8ton with log grapple supplier
Chinese wenyang machinery   log loader WY968J 8ton with log grapple supplier Chinese wenyang machinery   log loader WY968J 8ton with log grapple supplier Chinese wenyang machinery   log loader WY968J 8ton with log grapple supplier Chinese wenyang machinery   log loader WY968J 8ton with log grapple supplier

Large Image :  Chinese wenyang machinery log loader WY968J 8ton with log grapple

Product Details:

Place of Origin: China
Brand Name: Wenyang machinery
Certification: ISO 9001-2008 SGS
Model Number: WY968J

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Packaging Details: 1 unit /40HQ or by RORO
Delivery Time: 20 days after receiving deposit
Contact Now
Detailed Product Description
Rated Capacity: 8TON If OEM: Yes
Max Dumping Height: 3900mm Engine: Weichai
Engine Power: 175KW Operating Weight: 21TON
Dimension: 8700x3100x3600mm Moving Type: Wheel Loader

Chinese wenyang machinery log loader WY968J 8ton with log grapple



Chinese wenyang machinery   log loader WY968J 8ton with log grapple

Chinese wenyang machinery   log loader WY968J 8ton with log grapple

Chinese wenyang machinery   log loader WY968J 8ton with log grapple



Excellent performance

▼Engine ---the diesel SC11CB240.1G2B1 power 175kw,high-end engine ,high efficiency and low noise cooling technology . Powerful ,reliable performance .

▼Tnak----reinforced structure to ensure the tank intensity under vibration .Fuel tank capacity is 280L,can meet the oil demand after a long time and continuous operation .

▼Counterweight ---large steering angle and thick slabs counterweight ,not only reliable but also practical.

▼Boom cylinder ,the rotating bucket cylinder-reinforced type cylinder piston rod.

▼Drive axle-increase ,enhanced professional drive axle, bearing gears ,wheels hub, increase block bearing ,use special heavy vehicle brake materials and advanced hydraulic technology .Effectively guarantee the brake performance ,reduce the fault rate.

▼Boom---lengthen ,double-thick type boom, shifte within the fulcrum force ,increase and guarantee the strength.

▼Front and rear frame –special design and manufacture of the franme ,with a strong ability to support and lateral stability of the vehicle .

▼Tires ---front wheel for forestry special 26.5R25 steel wire tire.

Item Unit WY968J
Engine Model SC11CB240.1G2B1
Rated speed r/min 2200
Rated power Kw 175
Travel speed Forward gear I Km/h 6.5
II Km/h 12.3
III Km/h 24
III Km/h 24
Reserve gear Km/h 8
  Km/h 8
Overall dimension(L*W*H) mm 8700x3100x3600
Total weight Kg 21000
Rated load Kg 8000
Min turning radius Mm 6700
Max. Grade ability Mm 28
Max torque N.m 920
Maximum dump height (Flat at the bottom of the fork ) mm 3900
Maximum dump height (Fork tiled down) mm 3900
Tread   3000
Wheelbase   3470
Min ground clearance   560
Hydraulic torque Model   YT375x3
torque coefficient   3.166
Tyre   26.5-25
Tyre pressure (front) MPa 0.5
Tyre pressure (rear ) MPa 0.5
Clipping fork Distance of clipping fork mm 2600
Fork dimension mm 1986*2650*1851
Diameter range mm 1000-2000
Fuel tank capacity L 230
Hydraulic fuel tank capacity L 270
Pallet fork travel angle ° 95
