Application
Foam rubber clamps can efficiently and safely handle and stack any type of foam products including rubber, sponge, plastic case,chemical industry and chemical fiber, etc.
Features
1.Proven durable T-beam arm aluminium frame construction.
2.Superior arm-slide bearing for extended service life.
3.Excellent driver visibility.
4.Regenerative hydraulic valving for optimal arm speed.
5.Thin arm designed, easy to permit close stacking.
| Center@Load Center(kg@mm) | Catalog Order No. | Mounting Class | Opening Range | Arm Height | Arm Length | Frame Width | Arm Thickness | Overall Height | Vertical Center Of Gravity | Weight | Effective Thickness | Horizontal Center Of Gravity |
| 500@500 | FMS20D-001A | Ⅱ | 1260-2630 | 417 | 1040 | 47 | 665 | 221 | 465 | 465 | 127 | 310 |
| 600@500 | FMS20D-002A | Ⅱ | 850-2230 | 417 | 1041 | 47 | 665 | 221 | 430 | 430 | 127 | 280 |
| 500@1000 | FMS20D-003A | Ⅱ | 900-2300 | 400 | 1041 | 50 | 665 | 221 | 475 | 475 | 167 | 280 |
| 200@1000 | FMS20D-004A | Ⅱ | 1750-3150 | 400 | 1900 | 50 | 665 | 221 | 650 | 650 | 167 | 280 |
| 500@1000 | FMS20D-005A | Ⅱ | 1000-2400 | 400 | 141 | 50 | 665 | 221 | 490 | 490 | 167 | 280 |
| 1000@500 | FMS20D-006A | Ⅱ | 900-2300 | 600 | 1041 | 50 | 665 | 221 | 475 | 457 | 167 | 280 |
| 2200@500 | FMS30D-007B | Ⅲ | 790-2600 | 600 | 1600 | 60 | 730 | 250 | 800 | 800 | 200 | 280 |
| 2200@500 | FMS30D-008B | Ⅲ | 790-2600 | 400 | 1600 | 60 | 730 | 250 | 680 | 680 | 200 | 300 |
