Product Details:
Payment & Shipping Terms:
|
| Rated Capacity: | 3.5TON | Operating Weight: | 11620kg |
|---|---|---|---|
| Bucket Capacity: | 1.8m3 | Engine: | Cummins |
| Engine Power: | 97kW/2200rpm | Engine Model: | 6BTAA5.9-C130 |
Top Brand Wheel Loader Manufacturer
200,000 Units More Working Worldwide
Pay Loader, Chinese Pay Loader, Chinese Wheel Loader, Chinese 3T Wheel Loader, Chinese 5T Wheel Loader,
Chinese Large Wheel Loader, Chinese Small Wheel Loader, 1T-2.3T wheel loader
Cummins Engines and ZF Transmission & Axles
Pilot Control System, Automatic Leveling
Complete line of applications and accessories
Easy maintenance & Outstanding After-sales
Top brand quality, reliable and save 20% plus
POWERFUL DF CUMMINS ENGINE
LONKING TRANSMISSION
LONKING AXLES
JOYSTICK CONTROL
AC+ROPS&FOPS CABIN
VARIETY WITH ATTACHMENT
CONVENIENT MAINTENANCE
RATED POWER:97kW/2200rpm
BUCKET CAPACITY:1.8m³
RATED PAYLOAD:3500kg
OPERATING WEIGHT:11620kg
| CONFIGURATION |
| WEICHAI Engine |
| YD-13 Transmission |
| Electronic powershift control |
| YUNYU axles |
| Hydraulic actuated drum brake (parking brake) |
| single -lever (joystick )control |
| standard lift & bucket 1.8m3 |
| ROPS* FOPS cabin |
| Air conditioner |
| Radio & MP3 |
| LCD display |
| TECHNICAL PARAMETERS | ||
| Basic | Bucket capcity | 1.8m3 |
| Rated payload | 3500kg | |
| Operating weight | 11620±300kg | |
| Traction force | 106±3kN | |
| Breakout force | 103±3kN | |
| L*W*H | 7520*2500*3180mm | |
| Engine | Manufacturer/Model | CUMMINS /QSB6.7-C133 |
| Emission Standard | EPA(Tier III ) EU stage IIIA | |
| Engine type | 4 stroke ,turbocharged & charge air cooled , bosch electronic , diesel engine | |
| Rated power | 99kw(133HP)/2200rpm | |
| Rated torque | 584N.m/1450rmp | |
| Bore * Stroke (mm) | 107*124mm | |
| No.of cylinders /Displacement | 6/6.7L | |
| Air cleaner | Three stage air cleaner with cyclone pre-cleaner | |
| Alternator | 70Amp | |
| Baterry | 2-24V/105Ah | |
| Starting motor | 24V/5.8kW | |
| Heating capacity | 5000W | |
| Cooling capacity | 4700W | |
| Drive train | Transmission type | Countershaft powershift |
| Shift Type | Mechanical powershift control | |
| Pressure of transmission | 1.1-1.5MPa | |
| Torque converter | Single-stage & turbine ,3 element | |
| Axles | Rigid (front)& Oscillating (Rear) | |
| Rear axle Oscillation (°) | ±10° | |
| Differential | Conventional | |
| Main reducer | Spiral bevel gear 1-stage reduction | |
| Final reducer | Planetary reduction | |
| Tire | 17.5-25L-3 12PR TT | |
| Travel spped -forward | 6.5/12/32km/h | |
| Travel spped -reverse | 6.8/12.5/33.5km/h | |
| Brake system | Service brake | Single circuit caliper ,dry brake |
| Setting pressure | 0.70-0.78MPa | |
| Parking brake | Flexible shaft controlled | |
| Emergency brake | Caliper brake | |
| Steering system | Type | Hydaulic load sensor system |
| Pump | 246L/min 2200rpm | |
| System pressure | 14MPa | |
| Steering angle | ±35° | |
| Hydarulic system | Type | Joystick control (single lever) |
| Pump | 246L/min 2200rpm | |
| Control valve | 2 Spool | |
| System pressure | 16MPa | |
| Cycle time (sec) | 10.5 | |
| Service refill capacity | Fuel tank | 200L |
| Hydraulic tank | 173/178(3rd spool) | |
| Transmission type | 17L | |
| Front axle/ rear axle | 18.5L | |
| OPTIONAL |
| Oil bath air filter |
| 17.5R25 ** L-3TL |
| 3rdspool for Auxiliary function |
| sliding cabin window |
| electric heating rear window |
| lockable oil tank cap |
| rear view camera |
| bucket 2m3 |
| enlarged bucket 2.3m3 |
| coal bucket 2.5m3 |
| bucket (3 pieces cutting edges ) |
| log grapple |
| grass grapple |
| side tip bucket |
| log fork |
| quick hitch bucket |
| 4 in 1 bucket (quick hitch only ) |
| snow blade (quick hitch only ) |
| Cold starting (-35°C) |
| 20.5-25 L -3 16PR TT |
