Supply China made 4WD 1.5ton 0.7m3 bucket meet Euro III front end small wheel loader

I'm Online Chat Now

Supply China made 4WD 1.5ton 0.7m3 bucket meet Euro III front end small wheel loader

China Supply China made 4WD 1.5ton 0.7m3 bucket  meet Euro III front end small wheel loader supplier
Supply China made 4WD 1.5ton 0.7m3 bucket  meet Euro III front end small wheel loader supplier Supply China made 4WD 1.5ton 0.7m3 bucket  meet Euro III front end small wheel loader supplier

Large Image :  Supply China made 4WD 1.5ton 0.7m3 bucket meet Euro III front end small wheel loader

Product Details:

Place of Origin: China
Brand Name: Wenyang machinery
Certification: CE,SGS, ISO9001:2008
Model Number: WY15F

Payment & Shipping Terms:

Minimum Order Quantity: 1 uints
Packaging Details: 20GP container or 40HQ
Delivery Time: within 20 days after receiving deposit
Supply Ability: 800 units per year
Contact Now
Detailed Product Description
Rated Load: 1.5TON Bucket Capacity: 0.7m3
Engine Brand: Chinese Brand Yunnei Or Xinchai Engine Power: 37KW
Drive Model: Four Wheel Drive Operation: Joystick
Dumping Height: 2900mm



Supply China made 4WD 1.5ton 0.7m3 bucket meet Euro III front end small wheel loader





Supply China made 4WD 1.5ton 0.7m3 bucket  meet Euro III front end small wheel loader

Bucket Capacity(m³) 0.7
Operating Weight(kg) 3500
Bucket Width(mm) 1750
Rated Load(kg) 1500
Driving Mode Four-wheel drive
Overall Dimensions (mm)(L*W*H) 4900x1750x2790
Max. Breakout Force(KN) 32
Forward Speed 1st(km/h) 0-12
Forward Speed 2nd(km/h) 0-25
Reverse Speed (km/h) 0-25
Max. Dumping Height(mm) 2650
Optional Max. Dumping Height(mm) 2900
Max. Dumping Reach (mm) 850
Min. Turning Radius(mm) 3890
Full Bucket Lifting Time (s) 4.5
Total Hydraulic Cycle Time (s) 9
Tread Width (mm) 220
Wheel Base (mm) 1580
Min. Clearance Over Ground (mm) 230
MAX. Tilt Angel(°) 30
Diesel Engine Brand Yunnei Engine
  Optional brand

Euro3 and EPA Xinchai Engine

Yanmar/Perkins/Kubota/Cummins/Kohler EPA engine

  Type

In-line arrangement,Four-stroke,Water cooled,

4-cylinder diesel engine

  Rated Output(KW) 37
  Engine starting mode Electric
Transmission Type Fixed-spindle power shift with converter
Drive axle Type Isuzu drive axle
  Rear Axle Oscillation Center oscillation
  Oscillating Angle Of Rear Axle 13°
Tire Model 14/90-16
  Optional model

20.5-16 or 12-16.5 or 14-17.5 wider tire

31*15.5-15 Agriculture tire

295/80R22.5 or 315/80R22.5 Truck tire

Steering System Working Pressure (MPa) 10
  Max. Steering Angle (°) 35
Working Hydraulic System Pressure Of Tire (MPa) 2.5-3.5
  Working Pump Type Gear pump
  Working Pressure (MPa) 16
Brake System Service Brake Four Wheel Hydraulic spead-shoed brake
  Parking Brake Hand operated with disc brake
