Cross-country ability 23 ton granite shovel loader with pallet fork with max lifting height 3480mm

I'm Online Chat Now

Cross-country ability 23 ton granite shovel loader with pallet fork with max lifting height 3480mm

China Cross-country ability 23 ton granite shovel loader with pallet fork  with max lifting height 3480mm supplier
Cross-country ability 23 ton granite shovel loader with pallet fork  with max lifting height 3480mm supplier Cross-country ability 23 ton granite shovel loader with pallet fork  with max lifting height 3480mm supplier Cross-country ability 23 ton granite shovel loader with pallet fork  with max lifting height 3480mm supplier Cross-country ability 23 ton granite shovel loader with pallet fork  with max lifting height 3480mm supplier

Large Image :  Cross-country ability 23 ton granite shovel loader with pallet fork with max lifting height 3480mm

Product Details:

Place of Origin: China
Brand Name: Wenyang machinery
Certification: ISO ,CE
Model Number: WY968-23D forklift loader

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Packaging Details: 1 units /1*40HQ Or by RORO
Delivery Time: 25 days
Supply Ability: 1000 units per year
Contact Now
Detailed Product Description
Condition: New Rated Load: 23T
Enegine Brand: Weichai Engine Power: 178kw
Dimension: 8716X3030X3500mm Fork Dimension: 1500X230X110mm

Cross-country ability 23 ton granite shovel loader with pallet fork with max lifting height 3480mm



Cross-country ability 23 ton granite shovel loader with pallet fork  with max lifting height 3480mm



Cross-country ability 23 ton granite shovel loader with pallet fork  with max lifting height 3480mm

Cross-country ability 23 ton granite shovel loader with pallet fork  with max lifting height 3480mm

Superior performance:

Cross-country---to integrate advantages of cross-country forklift and wheel loader, also strengthened and improved systematically.

Safe---The strengthened whole machine system and driving room with safe designed, using of safe guard.



Energy-saving---top-grade WEICHAI engine which with multinomial patents and special technology, fuel-efficient and high efficiency and durable.



Multifunction---with fork or bucket for dual-purpose, driver’s cab can be used with or without safety guard and guardrail to carry out a tractor serves several purposes.

Description Specification Unit
Rated power 178 KW/h
Overall dimension(L x W x H) with fork 8716X3030X3500 mm
Max.lifting height 3480 mm
Operating weight 26000 kg
Rated Load / 2800mm 23000 kg
Rated load/1600mm 25000 kg
Bucket capacity 2.3 m3



Dimensions of fork

(L x W x H) 1500X230X110 mm
Distance of fork 1270 mm
Rated loading capacity 23000 kg
Driver’s guard Height 1680 mm
Turning angle +/-35 °
Turning radius 7350 mm
Wheel base 3500 mm
Tread 2300 mm
Min.Ground clearance 430 mm
Unloading angle 18 °
( with fork ) Haul location height (Ground clearance of material) 300 mm
Fuel tank capacity 380 L
Hydraulic fuel tank capacity 320 L
Specification of tyre 26.5-25
Engine System
Model WEICHAI ------WD10G240E21
Rated power 178kw(240hp)
Type Top-grade Diesel WEICHAI engine, co-worker of German Deutz Company and AVL technology, Austria; 6 Cylinders, Turbocharged Intercooled, with multinomial patents, synthesize multilevel compound desert air filter technology, high efficiency, low noise and cooling technology, especially using in dusty environment.
