Product Details:

Place of Origin: China
Brand Name: Wenyang machinery
Certification: ISO ,CE
Model Number: WY968-20D forklift loader

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Packaging Details: 1 units /1*40HQ Or by RORO
Delivery Time: 25 days
Supply Ability: 1000 units per year
Contact Now
Detailed Product Description
Condition: New Rated Load: 20T
Enegine Brand: Weichai Engine Power: 175kw
Dimension: 8550×3105×3300mm Fork Dimension: 1500×200×115mm

Wenyang machinery 20T stone block handling equipment forklift loader



Good quality 20T quarry fork loader with 175KW Weichai engine



Good quality 20T quarry fork loader with 175KW Weichai engine

Good quality 20T quarry fork loader with 175KW Weichai engine



Superior performance:

Cross-country---to integrate advantages of cross-country forklift and wheel loader, also strengthened and improved systematically.

Safe---the strengthened whole machine system and driving room with safe designed, using of safe guard.

Energy-saving---top-grade WEICHAI engine which with multinomial patents and special technology, fuel-efficient and high efficiency and durable.

Multifunction---with fork or bucket for dual-purpose, driver’s cab can be used with or without safety guard and guardrail to carry out a tractor serves several purposes.



Description Specifications Unit
Rated power 175 kw/h
Overall Dimension(L×W×H)(with safety guard) with fork 8550×3105×3300 mm
Max. lifting height with fork 3620
Operating weight 25500 kg
Rated loading capacity 20000 kg
Bucket capacity 2.7 m3
Dimensions of fork L×W×H 1500×200×115 mm
Distance of fork ≤1220 mm
Rated loading capacity 20000 kg
Safety guard Height 1680 mm
Driver’s cab Height 1680
Turning angle with fork ±32°
Turning radius with fork 7620
Wheel base 3375 mm
Tread 2415 mm
Min. Ground clearance 580 mm
Distance of rear axle to the link points 2300 mm
Front overhang length 2040 mm
Unloading angle with fork 16°
(With fork)Haul location height(Ground clearance of material) 300 mm
Turning radius when fork at haul location 6470 mm
Fuel tank capacity 280 L
Hydraulic fuel tank capacity 280 L
Specification of tyre front wheel 26.5-25-20PR
rear wheel 26.5-25-20PR
