High Quality warehouse lifting equipment 2t Hand Pallet Truck DB with Adjustable Cab

I'm Online Chat Now

High Quality warehouse lifting equipment 2t Hand Pallet Truck DB with Adjustable Cab

China High Quality warehouse lifting equipment 2t Hand Pallet Truck DB with Adjustable Cab supplier
High Quality warehouse lifting equipment 2t Hand Pallet Truck DB with Adjustable Cab supplier High Quality warehouse lifting equipment 2t Hand Pallet Truck DB with Adjustable Cab supplier High Quality warehouse lifting equipment 2t Hand Pallet Truck DB with Adjustable Cab supplier High Quality warehouse lifting equipment 2t Hand Pallet Truck DB with Adjustable Cab supplier

Large Image :  High Quality warehouse lifting equipment 2t Hand Pallet Truck DB with Adjustable Cab

Product Details:

Place of Origin: China
Brand Name: Wenyang Machinery
Certification: ISO CE

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Packaging Details: Exporting cargo
Contact Now
Detailed Product Description
Max Lifting Height:: 190mm Fork Length: 1150/1220mm
Rated Load: 2000kg Condition: New



Product Description
China made High quality 2T hand pallet truck DB with CE
• Standard epoxy powder coat finish which is resistant to chips and normal corrosion.
• Exceptionally strong but light weight steel construction, service weight is only 55kgs.
• With welded joints and reinforced fork tips for most durability in the toughest applications.
• 3 position hand control- Raise,Lower,Neutral.
• Excellent turning angle of 190 degrees facilities.
• Number of pump strokes 12 times, lift height per stroke 11mm.
• Reliable oil leak-proof hydraulic system.

Remark: Special size for width and length can be made according to customer's requirement.

Option:
(1)Nylon wheel, polyurethane wheel, rubber wheel,single fork roller or tandem fork rollers.
(2)Fork length:800mm,900mm,1000mm,1100mm.
Model   DB
Capacity Q(kg) 2000
Lowered fork height h13(mm) 75
Steering wheel mm φ160
Fork wheel single mm φ70×80
Fork wheel tandem mm φ70×60
Max. lift height h3(mm) 190
Total height h14(mm) 1176.5
Overall length l1(mm) 1520/1590
Fork length l(mm) 1150/1220
Width overall forks b5(mm) 520/550/680
Ground clearance,centre of wheelbase m2(mm) 22
Aisle width for pallets 1000×1200 crossways Ast(mm) 1720/1790
Aisle width for pallets 800×1200 lengthways Ast(mm) 1770/1790
Turning radius Wa(mm) 1265/1335
Service weight kg 55-60
