China WY280 0.8ton mini rubber track crawler skid steer loader

I'm Online Chat Now

China WY280 0.8ton mini rubber track crawler skid steer loader

China China WY280 0.8ton mini rubber track  crawler skid steer loader supplier
China WY280 0.8ton mini rubber track  crawler skid steer loader supplier China WY280 0.8ton mini rubber track  crawler skid steer loader supplier China WY280 0.8ton mini rubber track  crawler skid steer loader supplier

Large Image :  China WY280 0.8ton mini rubber track crawler skid steer loader

Product Details:

Place of Origin: China
Brand Name: Wenyang Machinery
Certification: CE,SGS, ISO9001:2008
Model Number: WY280

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: 6950-8000 USD /Set
Packaging Details: 20GP container
Delivery Time: with 20 days after receiving deposit
Payment Terms: T/T
Supply Ability: 800 units per year
Contact Now
Detailed Product Description
Type: Crawler Mini Skid Steer Loader Attachment: 4 In 1 Bucket
Condition: New Warranty Period: 1 Year
Operating Weight: 0.8ton

China WY280 0.8ton mini rubber track  crawler skid steer loaderChina WY280 0.8ton mini rubber track crawler skid steer loader
Easier maintenance

Thanks to open style design ,upper cover and back plate can be easily opened and removed & installed, all of these can make you replace the spare parts easily ,like air filter ,engine filter, oil filter , spark plug and so on .You also can easily discharge the wasted engine oil outside the body .

High –performance

Thanks to the compact structure design ,mini skid steer loader can enter into small spaces for working ,even the room .

Easy control

Only two joystick control running ,lifting and dumping .Large torque piston hydraulic motor makes running smoothly .Four wheel drive enables mini skid steer loader to walk in a variety of terrain .


ItemTrackSolid tireNormal tireLawn tireChevron tire
Max working height (H3)2065mm2032mm2072mm2072mm2060mm
Max pin height (H2)1803mm1769mm1809mm1809mm1798mm
Max discharge height (H1)1386mm1353mm1393mm1393mm1382mm
The highest unload distance (E)471mm508mm468mm468mm480mm
Max angle of unloading (α3)32°
Retracting angle (α2)33°
Angle of departure (α1)18°15°19°19°18°
Total height (H)1309mm1276mm1316mm1316mm1304mm
The height from the ground (H1)123mm90mm130mm130mm119mm
Wheelbase (L1)690mm686mm686mm686mm686mm
No bucket height (L3)1778mm1778mm1778mm1778mm1778mm
Total width (B2)800mm903mm903mm1053mm1030mm
Bucket width (B1)820mm820mm820mm820mm820mm
Total length (L) (with bucket)2210mm2210 mm2210mm2210mm2210mm
Turning radius (R)1236mm1237 mm1237mm1243mm1243mm


Main performance parameter :

ModelWY280
EngineRated power (KW)15.435KW(21HP)
Standard speed (rpm)3600
Noise (Db)≤95
Hydraulic systemSystem pressure (Mpa)17
Working time (s)RaiseTippingLow
4.271.343.31
Performance parameter MetricInch
Load weight165 Kg363.8 Lb
Bucket capacity0.12 m34.26 ft3
Max lifting power375 Kg827 Lb
Speed0-5.5 Km/h0-3.4 mlie/h

Operating
Weight

Solid tire794 Kg1750.5 Lb
Chevron tire744kg1636.8lb
Normal tire740Kg1631.4 Lb
Lawn tire704 Kg1552 Lb
Track855kg1884 Lb



China WY280 0.8ton mini rubber track  crawler skid steer loader
China WY280 0.8ton mini rubber track  crawler skid steer loader
